Optimize with Multi-Stage Dockerfile

Author photo
Cheppers Zrt.

Getting started Luckily, we have only hit a few minor snags in the process so far. For the most part, these first steps in rebuilding our website have been fairly simple, but we will still present them in detail. Any problems we had in this beginning stage were solved relatively easily. There are a few prerequisite steps you must take to begin working with Drupal 8. We usually use drush and make files to deploy our sites and we want to keep using this method with the new Drupal 8 site too.

Optimize with Multi-Stage Dockerfile

Let's take a look at a simple example: We have a single-page website. We have a static index.html, a single JavaScript, and a CSS file. As can be seen in this example, it's clean and short, but can be huge.

Here is our project directory tree:
|-- Gemfile
|-- Gemfile.lock
|-- Rakefile
| `-- index.html
`-- src
|-- css
||-- main.scss
| `-- modules
| `-- article.scss
`-- js
|-- boot.js
|-- init.js
`-- modules
`-- article.js

Our HTML is just a simple empty document:

<!DOCTYPE html>
<meta charset="utf-8"/>
<title>Sample Project for Multi-Stage Docker build</title>
<link rel="stylesheet" href="/app.css"/>
<script type="text/javascript"charset="utf-8"src="/app.js"></script>
<div id='mainContent'></div>

It's nice and clean. As we build a huge project, we don't want to write a single CSS and JavaScript file, so we create a beautiful directory structure, and before we deploy our site, we will merge them. For CSS we will use SCSS because it contains a lot of features that can be handy later. To build our project, we use simple rake tasks. So, we need ruby at least. For SCSS, we have to install extra packages such as libffi.

The old way

What did we do before Multi-Stage Dockerfiles?
Of course we want as small of a deploy image as possible so we create two Dockerfiles- one for building the project and one to deploy.
Firstly, building our project:

Now we can create much simpler image with pre-built artifacts:

# Dockerfile
FROM nginx:latest
COPY ./build-artifact /usr/share/nginx/html

Wow! Nice and clean but how can we deploy our site? What do we need to do to get the final image? Let's create a script so we can eliminate human error in the process:

# build. sh

# Build the "build-image"
docker build -t yitsushi/myshinyproject:build -f ./Dockerfile.build .

# Create a temporary container
docker create --name temp_container yitsushi/myshinyproject:build

# Extract build artifacts
docker cp temp_container:/application/public ./build-artifact

# delete the temporary container
docker rm -f temp_container

# Build the final image
docker build --no-cache -t yitsushi/myshinyproject:latest -f ./Dockerfile .

# Delete the temporary build-artifact directory
rm -rf ./build-artifact

It's ugly. We need a temporary image with a temporary container, and after that, we’ll need to create a local temporary directory. Don't forget to clean up your environment as well, like the build-artifact directory.

From here we simply execute our shell script:

❯ ./build.sh
Sending build context to Docker daemon 9.665MB
Step 1/6: FROM ruby:2.5.0-alpine3.7
---> 308418a1844f
Step 2/6: RUN apk add --no-cache build-base libffi-dev
---> Using cache
---> 677a75453610
Step 3/6: WORKDIR /application
---> Using cache
---> 1ba87d6eae13
Step 4/6: COPY docroot /application
---> f415c072262a
Step 5/6: RUN bundle install
---> Running in ba26aed32021
Fetching gem metadata from https://rubygems.org/...........
Fetching rake 12.3.0
Installing rake 12.3.0
Using bundler 1.16.1
Fetching ffi 1.9.18
Installing ffi 1.9.18 with native extensions
Fetching rb-fsevent 0.10.2
Installing rb-fsevent 0.10.2
Fetching rb-inotify 0.9.10
Installing rb-inotify 0.9.10
Fetching sass-listen 4.0.0
Installing sass-listen 4.0.0
Fetching sass 3.5.5
Installing sass 3.5.5
Bundle complete!2 Gemfile dependencies, 7 gems now installed.
Bundled gems are installed into `/usr/local/bundle`
Removing intermediate container ba26aed32021
---> 5e60801a48d2
Step 6/6: RUN bundle exec rake
---> Running in c685fe9c164a
Removing intermediate container c685fe9c164a
---> cb561d54cd0a
Successfully built cb561d54cd0a
Successfully tagged yitsushi/myshinyproject:build
Sending build context to Docker daemon 10.75kB
Step 1/2: FROM nginx:latest
---> 3f8a4339aadd
Step 2/2: COPY ./build-artifact /usr/share/nginx/html
---> f1fab6d81151
Successfully built f1fab6d81151
Successfully tagged yitsushi/myshinyproject:latest

❯ docker images
yitsushi/myshinyproject latest f1fab6d81151 9 minutes ago 108MB
yitsushi/myshinyproject build cb561d54cd0a 9 minutes ago 247MB

❯ docker run --rm -p 8888:80 yitsushi/myshinyproject

With Multi-Stage Dockerfile

Where can Multi-Stage Dockerfiles help us? We can eliminate all the unnecessary temporary files and containers. But how? We create only one Dockerfile with multiple FROM statement:

# Dockerfile, the new one
FROM ruby:2.5.0-alpine3.7 as builder

# Install dependencies fornative extensions
RUN apk add --no-cache build-base libffi-dev

# This will be our application root folder
WORKDIR /application

# Copy all the content from docroot
COPY docroot /application

# Build our application
RUN bundle install
RUN bundle exec rake

# Here we start a new stage
FROM nginx:latest
COPY --from=builder /application/public/usr/share/nginx/html

What?! Yes, that’s right- we can write a Dockerfile like this. We can define as many steps as we want, but keep in mind that it's not a "build more images at the same time" approach. In the end, only the last one will be available as the final image.
How can we build with this? We don't need our build.sh because it's that simple:

❯ docker build -t yitsushi/myshinyproject .
❯ docker images
yitsushi/myshinyproject latest 5ee4b57eb9e9 9 minutes ago 108MB
❯ docker run --rm -p 8888:80 yitsushi/myshinyproject

Hidden secret keys

What else can we do with Multi-Stage Dockerfiles? We can COPY a private ssh key to use in our build stage. However, in our production image, there will be no private ssh key.
Imagine: you have a private Go GitHub repository, and one of the dependencies is private as well. You can call go get, and there are two alternatives :

  • Add a deployment key to your Docker image;
  • Pre-fetch specific dependencies (or all).

Now we can add our key in a stage, fetch all repository, and- Voilà! Problem solved!

# Dockerfile with private ssh key
FROM golang:alpine as build

# Just add the key from build parameter
RUN mkdir -p /root/.ssh
ADD echo ${SSH_KEY}>/root/.ssh/private_key
RUN chmod 0600 /root/.ssh/private_key
RUN ssh-add /root/.ssh/private_key
RUN ssh-keyscan github.com>>/root/.ssh/known_hosts

ADD . /go/src/github.com/Yitsushi/myshinyproject
RUN go install github.com/Yitsushi/myshinyproject

# Final image
FROM alpine:latest
COPY --from=build /go/bin/myshinyproject /usr/local/bin/myshinyproject
CMD ["/usr/local/bin/myshinyproject"]

The image we’ll receive at the end will be as clean and small as possible. The build is still short and clear.

❯ docker build \
--build-arg SSH_KEY="$(cat ~/.ssh/cheppers_rsa)" \
-t yitsushi/myshinyproject \
-f Dockerfile .

Now we can deploy our image anywhere without exposing our private key after a local build.

Update: As Kaji Bikash pointed out, Docker can't see files outside of its scope during the build. So use SSH_KEY instead of SSH_KEY_PATH.


Docker gives us the opportunity to match our testing environment with our production environment as close as possible. But does this mean that our production environment must contain all the dependencies to build our project? This is a feature that’s already in there, but as I see it, it’s undeservedly underutilized. Perhaps the reason being that there are a few resources available on the topic. Or perhaps it wasn’t announced as loudly as some of the other features.

The source code is available on GitHub.
